Product Description
GENERAL SPECIFICATIONS
Bearing Type: BallBearing
Material: Impeller:Plastic;Frame:Aluminum Alloy
Lead Wire: ULType
Operation Temperature: -10℃-70℃, 35%-85%RH
Storage Temperature: -40℃-80℃, 35%-85%RH
1.The brushless external rotor motor is equipped with a coil inside, and the external permanent magnet rotates. In the case of the same outside diameter, it has a large moment of inertia, so it is generally designed into a disk, and the axial length is relatively short. It can be designed into multi-slot and multi-pole, low speed and high torque direct drive occasions, reducing product cost and reducing product volume.
2.Efficient heat dissipation, can quickly remove the internal heat of the equipment, ensure the stability of the system in high temperature environment.
3.Low noise and vibration suppression, suitable for scenes with high requirements for quiet environment.
4.Energy saving and environmental protection, DC fans are suitable for equipment that needs to run for a long time.
5.A wide range of applications, can be used in computer, communication products, optoelectronic products, consumer electronics, automotive electronic equipment, exchangers, medical equipment, heaters, air conditioners, frequency converters, cash machines, car freezer, welding machine, induction cooker, audio equipment, environmental protection equipment, refrigeration equipment and other traditional or modern instruments and equipment.
| Model | Size | Rating Voltage | Power Current | Power Consumption | Speed | Air Flow | Noise | Bearing | Weight |
| 17251D1HBL | 172*150*51 | 12 | 1.2 | 14 | 2300 | 120 | 50 | Ball | 550 |
| 17251D2HBL | 172*150*51 | 24 | 0.6 | 15 | 2300 | 120 | 50 | Ball | 550 |
